Festo 547014. Solenoid valve CDVI5.0-MT2H-1X3OLS-EXT
€198.22
Excl. 19% VAT ,
excl. Shipping Cost
Article
FES-547014
Manufacturer Nr.
CDVI5.0-MT2H-1X3OLS-EXT
Solenoid valve
Frequently Bought Together
-
This Item:
€198.22Excl. 19% VAT , excl. Shipping Cost
-
Festo 11546. Solenoid valve MFH-5-PK-3-L
€199.20Excl. 19% VAT , excl. Shipping Cost
-
Festo 567798. Solenoid valve MHJ10-S-2,5-QS-6-HF/LP
€71.96Excl. 19% VAT , excl. Shipping Cost
Total price
| Valve function | 3/2 open, single solenoid |
| Type of actuation | Electric |
| Standard nominal flow rate | 500 l/min |
| pneumatic working port | Sub-base |
| Operating voltage | 24V DC |
| Operating pressure | -0.9 bar ... 10 bar |
| Design | Piston gate valve |
| Type of reset | Pneumatic spring |
| Nominal size | 5 mm |
| Exhaust-air function | With flow control option |
| Sealing principle | Soft |
| Manual override | Non-detenting |
| Type of piloting | Pilot actuated |
| Pilot air supply | External |
| Flow direction | Reversible |
| Symbol | 00991789 |
| Note on forced dynamization | Switching frequency min. 1/month |
| Pilot pressure | 3 bar ... 8 bar |
| b value | 0.34 |
| C value | 2.05 l/sbar |
| Switching time off | 14 ms |
| Switching time on | 10 ms |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Note on operating and pilot medium | Lubricated operation possible (in which case lubricated operation will always be required) |
| Corrosion resistance class CRC | 3 - high corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B2-L |
| Media temperature | -5 °C ... 50 °C |
| Ambient temperature | -5 °C ... 50 °C |
| Product weight | 185 g |
| Type of mounting | Screw-in |
| Pilot exhaust port 82/84 | Sub-base |
| Pneumatic connection, port 1 | Sub-base |
| Pneumatic connection, port 2 | Sub-base |
| Pneumatic connection, port 3 | Sub-base |
| Pneumatic connection, port 4 | Sub-base |
| Pneumatic connection, port 5 | Sub-base |
| Note on materials | RoHS-compliant |
| Material seals | NBR TPE-O |
| Material housing | Die-cast aluminium |
| Manufacturer Nr. | CDVI5.0-MT2H-1X3OLS-EXT |
|---|---|
| Manufacturer | Festo |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| EAN | 4052568185718 |
| Weight | 0.210000 |
| HS-Code | 84812090 |
| Article authenticity | Original product |
| Condition of article | New |
