Festo 543922. Mini slide DGSL-6-20-P1A
Manufacturer Nr.
DGSL-6-20-P1A
Frequently Bought Together
Stroke 20 mm Adjustable end position range/length front 30.5 mm Adjustable end position range/length rear 15 mm Piston diameter 8 mm Operating mode, drive unit Yoke Cushioning Elastic cushioning rings/pads at both ends with fixed stop Mounting position optional Guide Ball bearing cage guide Design Yoke
Piston
Piston rod
Slide Position detection Via proximity switch Symbol 00991263 Operating pressure 0.15 MPa ... 0.8 MPa Operating pressure 1.5 bar ... 8 bar Max. speed 0.5 m/s Repetition accuracy ±0.01 mm Mode of operation Double-acting Operating medium Compressed air to ISO 8573-1:2010 [7:4:4] Note on operating and pilot medium Lubricated operation possible (in which case lubricated operation will always be required) Corrosion resistance class CRC 0 - No corrosion stress LABS (PWIS) conformity VDMA24364-B1/B2-L Ambient temperature 0 °C ... 60 °C Impact energy in end positions 0.02 J Cushioning length 2.8 mm Max. force Fy 590 N Max. force Fz 590 N Max. moment Mx 7 Nm Max. moment My 5 Nm Max. moment Mz 5 Nm Theoretical force at 0.6 MPa (6 bar, 87 psi), return stroke 23 N Theoretical force at 0.6 MPa (6 bar, 87 psi), advance stroke 30 N Moving mass 76 g Product weight 185 g alternative connections See product drawing Type of mounting With through-hole Pneumatic connection M3 Note on materials RoHS-compliant Material cover Wrought aluminium alloy Material seals HNBR Material housing Wrought aluminium alloy Material piston rod High-alloy stainless steel
More Information
Manufacturer Nr.
DGSL-6-20-P1A
Manufacturer
Festo
GPSR manufacturer information
Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
EAN
4052568182670
Weight
0.220000
HS-Code
84123100
Article authenticity
Original product
Condition of article
New
