Festo 556513. Swivel/linear unit DSL-32-50-270-P-A-S20-B
€1,294.29
Excl. 19% VAT ,
excl. Shipping Cost
Article
FES-556513
Manufacturer Nr.
DSL-32-50-270-P-A-S20-B
Swivel/linear unit
Frequently Bought Together
-
This Item:
€1,294.29Excl. 19% VAT , excl. Shipping Cost
-
Festo 556766. Swivel/linear unit DSL-40-160-270-CC-A-S20-KF-B
€3,161.80Excl. 19% VAT , excl. Shipping Cost
-
Festo 1369110. Semi-rotary drive DSM-12-270-HD-A-B
€503.98Excl. 19% VAT , excl. Shipping Cost
Total price
| Rotation angle adjustment range | 0 deg ... 270 deg |
| Stroke | 50 mm |
| Piston diameter | 32 mm |
| Swivel angle | 0 deg ... 272 deg |
| Cushioning | Elastic cushioning rings/plates at both ends |
| Mounting position | optional |
| Fine adjustment | -6 deg |
| Mode of operation | Double-acting |
| Design | Vane |
| Position detection | Via proximity switch |
| Symbol | 00991269 |
| Variants | Through, hollow piston rod |
| Protection against torque/guide | With plain-bearing guide |
| Operating pressure | 2.5 bar ... 8 bar |
| Max. impact speed | 0.5 m/s |
| Max. swivel frequency at 0.6 MPa (6 bar, 87 psi) | 2 Hz |
| Rotary angle backlash | 2 deg |
| Repetition accuracy | 1 deg |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Note on operating and pilot medium | Lubricated operation possible (in which case lubricated operation will always be required) |
| Corrosion resistance class CRC | 1 - Low corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B2-L |
| Ambient temperature | -10 °C ... 60 °C |
| Dynamic load torque | 0.8 Nm |
| Theoretical force at 0.6 MPa (6 bar, 87 psi), return stroke | 294 N |
| Theoretical force at 0.6 MPa (6 bar, 87 psi), advance stroke | 422.5 N |
| Theoretical torque at 0.6 MPa (6 bar, 87 psi) | 10 Nm |
| Permissible mass moment of inertia | 1.7E-4 kgm² |
| Product weight | 2840 g |
| Basic weight for 0 mm stroke | 2840 g |
| Additional weight per 10 mm stroke | 109 g |
| Type of mounting | Either: Clamped in T-slot Via male thread |
| Pneumatic connection | G1/8 |
| Material cover | Wrought aluminium alloy Anodised |
| Material seals | TPE-U(PU) |
| Material housing | Wrought aluminium alloy Smooth anodised |
| Material piston rod | Tempered steel |
| Manufacturer Nr. | DSL-32-50-270-P-A-S20-B |
|---|---|
| Manufacturer | Festo |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| EAN | 4052568200954 |
| Weight | 3.400000 |
| HS-Code | 84123900 |
| Article authenticity | Original product |
| Condition of article | New |
