Festo 562792. Electrical slide EGSK-46-400-20P
Manufacturer Nr.
EGSK-46-400-20P
Frequently Bought Together
Working stroke 400 mm Size 46 Reversing backlash theoretical 20 µm Spindle diameter 15 mm Spindle pitch 20 mm/U Mounting position optional Guide Recirculating ball bearing guide Design Electromechanical linear axis
With ball screw drive Referencing Reference switch Spindle type Ball screw drive Symbol 00991211 Max. acceleration 20 m/s² Max. speed 1.05 m/s Repetition accuracy ±0.01 mm Corrosion resistance class CRC 0 - No corrosion stress LABS (PWIS) conformity VDMA24364 zone III Degree of protection IP10 Ambient temperature 0 °C ... 40 °C Dynamic basic load rating fixed bearing 6600 N Dynamic basic load rating linear guide 21747 N Dynamic basic load rating ball screw 3040 N 2nd moment of area Iy 240000 mm⁴ 2nd moment of area Iz 1500000 mm⁴ Max. drive torque 0.61 Nm Max. force Fy 3904 N Max. force Fz 3904 N Max. moment Mx 115 Nm Max. moment My 38.7 Nm Max. moment Mz 38.7 Nm Max. feed force Fx 192 N Frictional torque independent of load 0.1 Nm Static basic load rating ball screw 7150 N Static basic load rating linear guide 45500 N Mass moment of inertia JH per metre of stroke 0.39 kgcm² Mass moment of inertia JO 0.154 kgcm² Feed constant 20 mm/U Static basic load rating fixed bearing 3240 N Reference value operational performance 10000 km Moving mass 910 g Weight of slide 910 g Product weight 10250 g Weight of additional slide 910 g Basic weight for 0 mm stroke 5170 g Additional weight per 10 mm stroke 127 g Type of mounting Via female thread and dowel pin Material end cap Die-cast aluminium
Coated Material profile Coated
High-alloy steel Note on materials RoHS-compliant Material drive cover Die-cast aluminium
Coated Material slide Steel Material spindle nut Steel Material spindle Steel
More Information
Manufacturer Nr.
EGSK-46-400-20P
Manufacturer
Festo
GPSR manufacturer information
Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
EAN
4052568210007
Weight
11.000000
HS-Code
84799070
Article authenticity
Original product
Condition of article
New
