Festo 543107. Power supply socket NECU-G78G5-C2
Manufacturer Nr.
NECU-G78G5-C2
Frequently Bought Together
Based on standard EN 61984 Approval c CSA us (OL) Product weight 50 g Electrical connection 1 Straight socket, 7/8", 5-pin Plug encoding NFPA/T3.5.29 R1-2003 Electrical connection 2 Screw terminal Operational voltage range DC 0 V ... 250 V Operational voltage range AC 0 V ... 250 V Permissible current load 8 A Immunity to surge 2.5 kV Permissible cable diameter 6 mm ... 12 mm Connection cross section 1.5 mm² Degree of protection IP67 Ambient temperature -25 °C ... 80 °C CE mark (see declaration of conformity) To EU Low Voltage Directive CE marking (see declaration of conformity) To UK regulations for electrical equipment LABS (PWIS) conformity VDMA24364-B2-L Note on materials RoHS-compliant Pollution degree 3 Corrosion resistance class CRC 1 - Low corrosion stress Material housing PA Housing colour Black Material union nut Nickel-plated die-cast zinc Material seals FPM
NBR Material electrical contact Gold-plated copper alloy
More Information
Manufacturer Nr.
NECU-G78G5-C2
Manufacturer
Festo
GPSR manufacturer information
Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
EAN
4052568091231
Weight
0.060000
HS-Code
85366990
Article authenticity
Original product
Condition of article
New
