Festo 537982. Sub-base VMPA2-IC-AP-S-1
€77.18
Excl. 19% VAT ,
excl. Shipping Cost
Article
FES-537982
Manufacturer Nr.
VMPA2-IC-AP-S-1
Sub-base
Frequently Bought Together
-
This Item:
€77.18Excl. 19% VAT , excl. Shipping Cost
-
Festo VMPAL-AP-20-QS5/16"-2-T1 (561034) Sub-Base
€36.97Excl. 19% VAT , excl. Shipping Cost
-
Festo 561030. Sub-base VMPAL-AP-10-QS5/32"-2-T1
€30.65Excl. 19% VAT , excl. Shipping Cost
Total price
| Width | 30.5 mm |
| Length | 107.3 mm |
| Grid dimension | 21 mm |
| Operating pressure | -0.09 MPa ... 1 MPa |
| Operating pressure | -0.9 bar ... 10 bar |
| Pilot pressure | 0.3 MPa ... 0.8 MPa |
| Pilot pressure | 3 bar ... 8 bar |
| Approval | c UL us - Recognized (OL) |
| KC mark | KC-EMV |
| CE mark (see declaration of conformity) | To EU EMC Directive In accordance with EU RoHS Directive |
| CE marking (see declaration of conformity) | To UK instructions for EMC To UK RoHS instructions |
| Corrosion resistance class CRC | 0 - No corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Ambient temperature | -5 °C ... 50 °C |
| Product weight | 233 g |
| Electrical connection | M8 Plugs |
| Mounting method for sub-base | With through-hole |
| Pilot air port 12/14 | M5 |
| Pilot exhaust port 82/84 | M5 |
| Pneumatic connection, port 1 | G1/8 |
| Pneumatic connection, port 2 | G1/8 |
| Pneumatic connection, port 3 | G1/8 |
| Pneumatic connection, port 4 | G1/8 |
| Pneumatic connection, port 5 | G1/8 |
| Note on materials | RoHS-compliant |
| Material sub-base | Die-cast aluminium |
| Manufacturer Nr. | VMPA2-IC-AP-S-1 |
|---|---|
| Manufacturer | Festo |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| EAN | 4052568175061 |
| Weight | 0.250000 |
| HS-Code | 84819000 |
| Article authenticity | Original product |
| Condition of article | New |
