Festo 4137. T quick connector TCK-1/8-PK-3
Manufacturer Nr.
TCK-1/8-PK-3
Festo 4137. T quick connector TCK-1/8-PK-3 is available to buy in increments of 10
Frequently Bought Together
Nominal size 2 mm Type of seal on screwed plug Sealing ring Mounting position optional Design T-shape Size of pack 10 Operating pressure complete temperature range -0.095 MPa ... 1 MPa Operating pressure complete temperature range -0.95 bar ... 10 bar Operating pressure complete temperature range -13.775 psi ... 145 psi Operating medium Compressed air to ISO 8573-1:2010 [7:-:-] Note on operating and pilot medium Lubricated operation possible Corrosion resistance class CRC 1 - Low corrosion stress LABS (PWIS) conformity VDMA24364-B1/B2-L Ambient temperature -10 °C ... 60 °C Nominal torque 3.5 Nm Tolerance for nominal tightening torque ± 20% Pneumatic connection, port 1 Male thread G1/8 Pneumatic connection, port 2 For tubing outside diameter of 4 mm
For barbed fitting I.D. 3 mm with nut Material union nut Wrought aluminium alloy, anodised Note on materials RoHS-compliant Material sealing ring Reinforced PA
TPE-U(PU) Material housing Die-cast zinc Material hollow bolt Wrought aluminium alloy, anodised Material swivel fitting Die-cast zinc
More Information
Manufacturer Nr.
TCK-1/8-PK-3
Manufacturer
Festo
GPSR manufacturer information
Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
EAN
4052568018740
Weight
0.016000
HS-Code
79070000
Article authenticity
Original product
Condition of article
New
