Festo 153329. Push-in connector QSM-6H-4

Name: Festo 153329. Push-in connector QSM-6H-4
Brand: Festo
SKU: FES-153329
Price: 2.43 EUR
Availability: InStock

€2.43

Excl. 19% VAT , excl. Shipping Cost

Article

FES-153329

Manufacturer Nr.

QSM-6H-4

Push-in connector

Festo 153329. Push-in connector QSM-6H-4 is available to buy in increments of 10

Pictures are for reference and may not be accurate, actual product may differ

Frequently Bought Together

This Item: Festo 153329. Push-in connector QSM-6H-4
€2.43
Excl. 19% VAT , excl. Shipping Cost
Festo 153382. Blanking plug QSMC-3H
€0.66
Excl. 19% VAT , excl. Shipping Cost
Festo 153326. Push-in connector QSM-4-3
€2.43
Excl. 19% VAT , excl. Shipping Cost

Total price

Size	Mini
Nominal size	2.6 mm
Mounting position	optional
Design	Straight design
Size of pack	10
Design	Push-pull principle
Operating pressure complete temperature range	-0.095 MPa ... 0.6 MPa
Operating pressure complete temperature range	-0.95 bar ... 6 bar
Operating pressure complete temperature range	-13.775 psi ... 87 psi
Temperature-dependent operating pressure	-0.095 MPa ... 1.4 MPa
Temperature-dependent operating pressure	-0.95 bar ... 14 bar
Temperature-dependent operating pressure	-13.775 psi ... 203 psi
Maritime classification	See certificate
Operating medium	Compressed air to ISO 8573-1:2010 [7:-:-]
Note on operating and pilot medium	Lubricated operation possible
Corrosion resistance class CRC	1 - Low corrosion stress
LABS (PWIS) conformity	VDMA24364-B1/B2-L
Ambient temperature	-10 °C ... 80 °C
Product weight	2.4 g
Pneumatic connection, port 1	Push-in sleeve Ø 6 mm
Pneumatic connection, port 2	For tubing outside diameter of 4 mm
Colour of release ring	Blue
Note on materials	RoHS-compliant
Material housing	PBT
Material release ring	POM
Material tubing seal	NBR
Material tubing clamp component	High-alloy stainless steel

More Information
Manufacturer Nr.	QSM-6H-4
Manufacturer	Festo
GPSR manufacturer information	Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
EAN	4052568033927
Weight	0.001700
HS-Code	39174000
Article authenticity	Original product
Condition of article	New
