Festo SIES-QB-PO-K-L (150489) Proximity Sensor
Manufacturer Nr.
SIES-QB-PO-K-L
Frequently Bought Together
Complies to standard EN 60947-5-2 Permission RCM mark CE certificate (see declaration of conformity) to EU EMC directive Material information Copper and PTFE-free Measurement switching distance [mm] 2,0 Secured safety distance [mm] 1,60 Reduction factors aluminium = 0,45 ambient temperature [°C] -25 to 85 Repeatability [mm] 0,10 Control output PNP Switching element function NC contact Max. switching frequency [Hz] 1.200 Max. switching frequency DC [Hz] 1.200 Max. output current depending on temperature 150 mA at <= 85 °C Voltage drop [V] 3,2 Short circuit resistance Cycling Operating voltage range DC [V] 10 to 30 residual ripple 10 % Empty run current [mA] <= 30 mA Reverse polarity protection for all electrical connections Electrical connection 3-wire Cable length [MTR] 2,5 Cable sleeve material TPE-U(PUR) size 12x26x40 mm Fastening type With throughway bores Integration type flush Product weight [g] 170 Housing material PBT reinforced Switching status indicator LED yellow Protection category IP67
More Information
Manufacturer Nr.
SIES-QB-PO-K-L
Manufacturer
Festo
GPSR manufacturer information
Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
EAN
4052568069759
Weight
0.095000
HS-Code
85365019
Article authenticity
Original product
Condition of article
New
