Festo 538314. Proximity sensor SIEF-M12NB-NS-K-L
Manufacturer Nr.
SIEF-M12NB-NS-K-L
Frequently Bought Together
Design Round Conforms to standard EN 60947-5-2 Symbol 00991704 Approval RCM trademark
c UL us listed (OL) CE mark (see declaration of conformity) To EU EMC Directive Measuring principle Inductive Rated operating distance 8 mm Assured operating distance 6.48 mm Reduction factors Aluminium = 1.0
Stainless steel St 18/8 = 1.0
Copper = 1.0
Brass = 1.0
Steel St 37 = 1.0 Ambient temperature -30 °C ... 85 °C Repetition accuracy 0.16 mm Switching output NPN Switching element function N/O contact Hysteresis 0.24 mm ... 1.2 mm Max. switching frequency DC 2000 Hz Max. output current 200 mA Voltage drop 1.8 V Short circuit current rating Pulsed Operational voltage range DC 10 V ... 30 V Residual ripple 10 % No-load supply current 15 mA Reverse polarity protection For all electrical connections Electrical connection 3-wire
Cable Cable length 2.5 m Material cable sheath TPE-U(PUR) Material insulating sheath PVC Size M12 Type of mounting Via lock nut Tightening torque 10 Nm Mounting type Partially flush Product weight 120 g Material housing Brass
PBT
Chrome-plated Switching status indication Yellow LED Ambient temperature with moving cable 0 °C ... 80 °C Degree of protection IP67 Immunity to magnetic fields Magnetic direct and alternating field Corrosion resistance class CRC 2 - Moderate corrosion stress Additional information for sensor selection Reduction factor 1, resistant to magnetic fields Electrical output NPN Selection of sensor design Standard
More Information
Manufacturer Nr.
SIEF-M12NB-NS-K-L
Manufacturer
Festo
GPSR manufacturer information
Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
EAN
4052568089177
Weight
0.120000
HS-Code
85365019
Article authenticity
Original product
Condition of article
New
