Festo 2949. Roller lever valve RS-4-1/8
Manufacturer Nr.
RS-4-1/8
Frequently Bought Together
Valve function 4/2-way, single solenoid Type of actuation Mechanical Standard nominal flow rate 128 l/min pneumatic working port G1/8 Operating pressure 0.35 MPa ... 0.8 MPa Operating pressure 3.5 bar ... 8 bar Design Poppet seat Type of reset Mechanical spring Nominal size 3.5 mm Exhaust-air function With flow control option Sealing principle Soft Mounting position optional Type of piloting Pilot actuated Pilot air supply Internal Flow direction Non-reversible Symbol 00991139 Pilot medium Compressed air to ISO 8573-1:2010 [-:-:-] Note on forced dynamization Switching frequency min. 1/year Explosion protection Zone 1 (ATEX)
Zone 2 (ATEX)
Zone 21 (ATEX)
Zone 22 (ATEX) Operating medium Compressed air to ISO 8573-1:2010 [-:-:-] Note on operating and pilot medium Lubricated operation possible (in which case lubricated operation will always be required) Corrosion resistance class CRC 2 - Moderate corrosion stress LABS (PWIS) conformity VDMA24364-B1/B2-L Media temperature -10 °C ... 60 °C Ambient temperature -10 °C ... 60 °C Actuating force 1.77 N Product weight 230 g Type of mounting With through-hole Pneumatic connection, port 1 G1/8 Pneumatic connection, port 2 G1/8 Pneumatic connection, port 3 G1/8 Pneumatic connection, port 4 G1/8 Note on materials RoHS-compliant Material seals NBR Material housing Aluminium
Anodised
More Information
Manufacturer Nr.
RS-4-1/8
Manufacturer
Festo
GPSR manufacturer information
Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
EAN
4052568110253
Weight
0.185000
HS-Code
84812090
Article authenticity
Original product
Condition of article
New
