Festo 525187. Solenoid valve MHE4-MS1H-3/2G-1/4
€105.11
Excl. 19% VAT ,
excl. Shipping Cost
Article
FES-525187
Manufacturer Nr.
MHE4-MS1H-3/2G-1/4
Solenoid valve
Frequently Bought Together
-
This Item:
€105.11Excl. 19% VAT , excl. Shipping Cost
-
Festo 4514930. Valve VOFC-L-B52-FG14-F19A
€486.89Excl. 19% VAT , excl. Shipping Cost
-
Festo 8025224. Solenoid valve MHA1-M4R-3/2G-0,6-P3
€20.22Excl. 19% VAT , excl. Shipping Cost
Total price
| Valve function | 3/2-way, closed, monostable |
| Type of actuation | Electric |
| Construction width | 18 mm |
| Standard nominal flow rate | 400 l/min |
| pneumatic working port | G1/4 |
| Operating voltage | 24V DC |
| Operating pressure | -0.09 MPa ... 0.8 MPa |
| Operating pressure | -0.9 bar ... 8 bar |
| Design | Pressure-relieved poppet valve |
| Type of reset | Mechanical spring |
| Degree of protection | IP65 |
| Approval | RCM trademark c UL us - Recognized (OL) |
| CE mark (see declaration of conformity) | To EU EMC Directive In accordance with EU RoHS Directive |
| CE marking (see declaration of conformity) | To UK instructions for EMC To UK RoHS instructions |
| Nominal size | 4 mm |
| Grid dimension | 24 mm |
| Note on grid dimension | Minimum distance between the valves is 6 mm |
| Exhaust-air function | With flow control option |
| Sealing principle | Soft |
| Mounting position | optional |
| Manual override | Non-detenting |
| Type of piloting | Direct |
| Flow direction | Reversible with restrictions |
| Symbol | 00991308 |
| lap | Underlap |
| Reverse polarity protection | Bipolar |
| Additional functions | Spark arresting Holding current reduction Protective circuit |
| Operating pressure, reversible | -0.09 MPa ... 0.1 MPa |
| Operating pressure, reversible | -0.9 bar ... 1 bar |
| Operating pressure, reversible | -13.05 psi ... 14.5 psi |
| Max. switching frequency | 210 Hz |
| Switching time off | 3.5 ms |
| Switching time on | 3.5 ms |
| Tolerance switching time off | +10%/-40% |
| Tolerance switching time on | +10%/-30% |
| Switching time dispersion from 1 Hz | 0.3 ms |
| Duty cycle | 100% |
| Characteristic coil data | 24 V DC: low-current phase 2.125 W, high-current phase 8.5 W |
| Permissible voltage fluctuations | +/- 10 % |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Note on operating and pilot medium | Lubricated operation possible (in which case lubricated operation will always be required) |
| Vibration resistance | Transport application test with severity level 2 to FN 942017-4 and EN 60068-2-6 |
| Shock resistance | Shock test with severity level 2 to FN 942017-5 and EN 60068-2-27 |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Media temperature | -5 °C ... 60 °C |
| Ambient temperature | -5 °C ... 60 °C |
| Product weight | 270 g |
| Electrical connection | 2-pin Plugs |
| Type of mounting | With through-hole |
| Pneumatic connection, port 1 | G1/4 |
| Pneumatic connection, port 2 | G1/4 |
| Pneumatic connection, port 3 | G1/4 |
| Note on materials | RoHS-compliant |
| Material seals | HNBR NBR |
| Material housing | Die-cast zinc, coated |
| Material screws | Galvanised steel |
| Manufacturer Nr. | MHE4-MS1H-3/2G-1/4 |
|---|---|
| Manufacturer | Festo |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| EAN | 4052568161521 |
| Weight | 0.280000 |
| HS-Code | 84812090 |
| Article authenticity | Original product |
| Condition of article | New |
