Festo 534340. One-way flow control valve GRLA-1/4-QS-10-RS-D
€17.62
Excl. 19% VAT ,
excl. Shipping Cost
Article
FES-534340
Manufacturer Nr.
GRLA-1/4-QS-10-RS-D
One-way flow control valve
Frequently Bought Together
-
This Item:
€17.62Excl. 19% VAT , excl. Shipping Cost
-
Festo 13229. Precision flow control valve GRPO-10-PK-3
€114.75Excl. 19% VAT , excl. Shipping Cost
-
Festo 161405. One-way flow control valve CRGRLA-1/4-B
€63.84Excl. 19% VAT , excl. Shipping Cost
Total price
| Valve function | One-way flow control function |
| Pneumatic connection, port 1 | QS-10 |
| Pneumatic connection, port 2 | G1/4 |
| Adjustment component | Knurled screw |
| Type of mounting | Screw-in Via male thread |
| Standard nominal flow rate in flow control direction | 480 l/min |
| Standard nominal flow rate in blocked direction | 345 l/min ... 500 l/min |
| Operating pressure | 0.2 bar ... 10 bar |
| Ambient temperature | -10 °C ... 60 °C |
| Maritime classification | See certificate |
| Mounting position | optional |
| Symbol | 00991452 |
| Operating pressure complete temperature range | 0.2 bar ... 10 bar |
| Standard flow rate in flow control direction 0.6->0 MPa (6->0 bar, 87->0 psi) | 760 l/min |
| Standard flow rate in non-return direction 0.6->0 MPa (6->0 bar, 87->0 psi) | 630 l/min ... 790 l/min |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Note on operating and pilot medium | Lubricated operation possible (in which case lubricated operation will always be required) |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Storage temperature | -10 °C ... 40 °C |
| Media temperature | -10 °C ... 60 °C |
| Nominal torque | 5 Nm |
| Product weight | 50 g |
| Note on materials | RoHS-compliant |
| Material seals | NBR |
| Material hollow bolt | Wrought aluminium alloy Anodised |
| Material release ring | POM |
| Material knurled head | Wrought aluminium alloy Anodised |
| Material adjusting screw | High-alloy stainless steel |
| Material swivel fitting | Die-cast zinc |
| Manufacturer Nr. | GRLA-1/4-QS-10-RS-D |
|---|---|
| Manufacturer | Festo |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| EAN | 4052568048907 |
| Weight | 0.048000 |
| HS-Code | 84812090 |
| Article authenticity | Original product |
| Condition of article | New |
