Festo 534415. Solenoid valve VMPA1-M1H-X-PI
Manufacturer Nr.
VMPA1-M1H-X-PI
Frequently Bought Together
Valve function 3/2-way, closed, monostable Type of actuation Electric Valve size 10 mm Standard nominal flow rate 255 l/min Operating voltage 24V DC Operating pressure -0.09 MPa ... 1 MPa Operating pressure -0.9 bar ... 10 bar Design Piston gate valve Type of reset Pneumatic spring Approval c UL us - Recognized (OL) Degree of protection IP65
To IEC 60529 Sealing principle Soft Mounting position optional Manual override Detenting
Non-detenting Type of piloting Pilot actuated Flow direction Reversible Symbol 00991175 lap Positive overlap Signal status display yes Pilot pressure 0.3 MPa ... 0.8 MPa Pilot pressure 3 bar ... 8 bar Suitability for vacuum yes Standard nominal flow rate with QS-6 255 l/min Switching time off 20 ms Switching time on 10 ms Max. positive test pulse with 0 signal 400 µs Max. negative test pulse with 1 signal 200 µs Permissible voltage fluctuations +/- 25% Operating medium Compressed air to ISO 8573-1:2010 [7:4:4] Note on operating and pilot medium Lubricated operation possible (in which case lubricated operation will always be required) Vibration resistance Transport application test with severity level 2 to FN 942017-4 and EN 60068-2-6 Shock resistance Shock test with severity level 2 to FN 942017-5 and EN 60068-2-27 Corrosion resistance class CRC 1 - Low corrosion stress LABS (PWIS) conformity VDMA24364-B1/B2-L Storage temperature -20 °C ... 40 °C Media temperature -5 °C ... 50 °C Relative air humidity Max. 90% at 40°C Ambient temperature -5 °C ... 50 °C Max. tightening torque for valve mounting 0.25 Nm Product weight 49 g Type of mounting With through-hole Note on materials RoHS-compliant Material seals NBR Material housing Die-cast aluminium
More Information
Manufacturer Nr.
VMPA1-M1H-X-PI
Manufacturer
Festo
GPSR manufacturer information
Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
EAN
4052568168032
Weight
0.055000
HS-Code
84812090
Article authenticity
Original product
Condition of article
New
