Festo 195750. Input module CPX-8DE
Frequently Bought Together
Dimensions (W x L x H) (incl. interlinking block and connection technology)
50 x 107 x 50 mm Product weight 39 g Ambient temperature -5 °C ... 50 °C Storage temperature -20 °C ... 70 °C Degree of protection Dependent on the manifold block Corrosion resistance class CRC 1 - Low corrosion stress
(when installed) LABS (PWIS) conformity VDMA24364-B2-L Material housing PA-reinforced
PC LED display 1 Group diagnostics
8 Channel status Diagnosis Short circuit/overload per channel Parameterisation Input debounce time
Signal extension time
Behaviour after short circuit
Module monitoring Operational voltage range DC 18 V ... 30 V Nominal operating voltage DC 24 V Intern power consumption nominal operating voltage Typ. 15 mA Number of inputs 8 Characteristic for inputs IEC1131-T2 Switching level Signal 0: <= 5 V
Signal 1: >= 11 V Switching logic for inputs PNP (positive switching) Input debounce time 3 ms (0.1 ms, 10 ms, 20 ms, parameterisable) Max. residual current of inputs per module 1 A Isolation channel - channel no Isolation channel - internal bus no Fuse protection (short circuit) Internal electronic fuse per module
More Information
Manufacturer Nr.
CPX-8DE
Manufacturer
Festo
GPSR manufacturer information
Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
EAN
4052568015312
Weight
0.105000
HS-Code
85389099
Article authenticity
Original product
Condition of article
New
