Festo 151689. Plug socket with cable KMEB-1-24-5-LED
Manufacturer Nr.
KMEB-1-24-5-LED
Frequently Bought Together
Signal status display Yellow LED Mounting position optional Product weight 230 g Electrical connection 1 Socket, to EN 175301-803, type C Electrical connection 1, design Angular Electrical connection 1, connection type Socket Electrical connection 1, cable outlet Angled Electrical connection 1, note on cable outlet 90° Electrical connection 1, number of connections/cores 3 Electrical connection 1, type of mounting On solenoid valve via M2.5 central screw Electrical connection 2, connector system Open end Electrical connection 2, number of connections/cores 3 Nominal operating voltage DC 24 V Immunity to surge 0.8 kV Protective conductor connection Available Cable length 5 m Cable characteristic Standard Cable diameter 5.2 mm Cable structure 3 x 0.5 mm² Wire ends Wire end sleeve Degree of protection IP65
To IEC 60529 Ambient temperature -20 °C ... 80 °C CE mark (see declaration of conformity) In accordance with EU RoHS Directive CE marking (see declaration of conformity) To UK RoHS instructions LABS (PWIS) conformity VDMA24364-B2-L Pollution degree 3 Corrosion resistance class CRC 1 - Low corrosion stress Material cable sheath PVC Material housing PA66-GF30 Material seals NBR Material electrical contact Silver-plated copper alloy
More Information
Manufacturer Nr.
KMEB-1-24-5-LED
Manufacturer
Festo
GPSR manufacturer information
Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
EAN
4052568010737
Weight
0.230000
HS-Code
85444290
Article authenticity
Original product
Condition of article
New
