Festo 189362. Suction cup complete ESS-100-EN
Manufacturer Nr.
ESS-100-EN
Frequently Bought Together
Min. workpiece radius 200 mm Nominal size 6 mm Suction cup diameter 100 mm Suction cup volume 84.66 cm³ Position of connection Top Mounting position optional Symbol 00991485 Correlation to suction-cup holder Size 5 Suction cup shape Round extra deep Operating pressure -0.095 MPa ... 0 MPa Operating pressure -0.95 bar ... 0 bar Operating pressure -13.775 psi ... 0 psi Nominal operating pressure -0.07 MPa Nominal operating pressure -0.7 bar Nominal operating pressure -10.15 psi Operating medium Atmospheric air based on ISO 8573-1:2010 [7:-:-] Corrosion resistance class CRC 1 - Low corrosion stress LABS (PWIS) conformity VDMA24364-A1-L Suitable for use with food See supplementary material information Ambient temperature -10 °C ... 70 °C Holding force at nominal operating pressure 440.8 N Lateral force at nominal operating pressure 351 N Product weight 228 g Type of mounting Via vacuum port Vacuum connection M10 Colour Black Shore hardness 60 +/- 5 Material screwed plug POM
Nickel-plated steel
Steel, galvanised and chrome-plated Note on materials RoHS-compliant Material suction cup NBR
More Information
Manufacturer Nr.
ESS-100-EN
Manufacturer
Festo
GPSR manufacturer information
Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
EAN
4052568149932
Weight
0.290000
HS-Code
84799070
Article authenticity
Original product
Condition of article
New
