Festo 529351. Feed separator HPV-14-20-A
€564.20
Excl. 19% VAT ,
excl. Shipping Cost
Article
FES-529351
Manufacturer Nr.
HPV-14-20-A
Feed separator
Frequently Bought Together
-
This Item:
€564.20Excl. 19% VAT , excl. Shipping Cost
-
Festo 576148. Stopper cylinder DFSP-50-25-DS-PA
€154.84Excl. 19% VAT , excl. Shipping Cost
-
Festo 576123. Stopper cylinder DFSP-40-20-DS-PA
€125.66Excl. 19% VAT , excl. Shipping Cost
Total price
| Stroke | 20 mm |
| Piston diameter | 14 mm |
| Max. replacement accuracy | 0.3 mm |
| Max. stem backlash Sx | 0.05 mm |
| Max. stem backlash Sz | 0.03 mm |
| Max. angular gripper jaw backlash ax | 0.12 deg |
| Max. angular gripper jaw backlash ay | 0.2 deg |
| Max. angular gripper jaw backlash az | 0.175 deg |
| Mounting of external fingers | Through-hole |
| Cushioning | No cushioning |
| Mounting position | optional |
| Mode of operation | Double-acting |
| Design | Twin piston Piston rod Locking mechanism Non-rotating |
| Position detection | Via proximity switch |
| Half pulse | 111.5 ms |
| Symbol | 00991914 |
| Protection against torque/guide | Square guide |
| Cycle time | 223 ms |
| Operating pressure | 3 bar ... 8 bar |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Note on operating and pilot medium | Lubricated operation possible (in which case lubricated operation will always be required) |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B2-L |
| Ambient temperature | 5 °C ... 60 °C |
| Max. force on finger Fz static | 100 N |
| Max. torque Mr at finger, static | 5 Nm |
| Max. torque at finger Mx static | 5 Nm |
| Max. torque at finger My static | 5 Nm |
| Theoretical force at 0.6 MPa (6 bar, 87 psi), return stroke | 75 N |
| Theoretical force at 0.6 MPa (6 bar, 87 psi), advance stroke | 90 N |
| Product weight | 290 g |
| Max. mass per external gripper finger | 150 g |
| alternative connections | M5 |
| Type of mounting | Either: Via female thread and centring sleeve Via through-hole and centring sleeve |
| Pneumatic connection | M5 |
| Manufacturer Nr. | HPV-14-20-A |
|---|---|
| Manufacturer | Festo |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| EAN | 4052568015657 |
| Weight | 0.330000 |
| HS-Code | 84798997 |
| Article authenticity | Original product |
| Condition of article | New |
