Festo 175832. Semi-rotary drive DSM-10-240-P-A-FF

Name: Festo 175832. Semi-rotary drive DSM-10-240-P-A-FF
Brand: Festo
SKU: FES-175832
Price: 371.04 EUR
Availability: InStock

€371.04

Excl. 19% VAT , excl. Shipping Cost

Article

FES-175832

Manufacturer Nr.

DSM-10-240-P-A-FF

Semi-rotary drive

Pictures are for reference and may not be accurate, actual product may differ

Frequently Bought Together

This Item: Festo 175832. Semi-rotary drive DSM-10-240-P-A-FF
€371.04
Excl. 19% VAT , excl. Shipping Cost
Festo 556633. Swivel/linear unit DSL-20-50-270-P-A-S20-KF-B
€1,569.23
Excl. 19% VAT , excl. Shipping Cost
Festo 185938. Semi-rotary drive DSM-8-180-P-FF-FW
€334.64
Excl. 19% VAT , excl. Shipping Cost

Total price

Size	10
Cushioning angle	0 deg
Rotation angle adjustment range	0 deg ... 200 deg
Swivel angle	0 deg ... 200 deg
Mounting position	optional
Fine adjustment	-5 deg
Mode of operation	Double-acting
Design	Vane
Position detection	Via proximity switch
Symbol	00991265
Operating pressure	2.5 bar ... 8 bar
Max. swivel frequency at 0.6 MPa (6 bar, 87 psi)	2 Hz
Operating medium	Compressed air to ISO 8573-1:2010 [7:4:4]
Note on operating and pilot medium	Lubricated operation possible (in which case lubricated operation will always be required)
LABS (PWIS) conformity	VDMA24364-B1/B2-L
Ambient temperature	0 °C ... 60 °C
Theoretical torque at 0.6 MPa (6 bar, 87 psi)	0.85 Nm
Permissible mass moment of inertia	0.0026 kgm²
Product weight	255 g
Type of mounting	Via female thread
Pneumatic connection	M3
Note on materials	RoHS-compliant
Material drive shaft	High-alloy stainless steel
Material seals	TPE-U(PU)
Material housing	Aluminium Anodised

More Information
Manufacturer Nr.	DSM-10-240-P-A-FF
Manufacturer	Festo
GPSR manufacturer information	Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
EAN	4052568143473
Weight	0.300000
HS-Code	84123900
Article authenticity	Original product
Condition of article	New
