Festo 170853. Guided drive DFM-25-100-P-A-GF
€313.58
Excl. 19% VAT ,
excl. Shipping Cost
Article
FES-170853
Manufacturer Nr.
DFM-25-100-P-A-GF
Guided drive
Frequently Bought Together
-
This Item:
€313.58Excl. 19% VAT , excl. Shipping Cost
-
Festo 189463. Mini guided drive DFC-6-15-P-A-KF
€440.63Excl. 19% VAT , excl. Shipping Cost
-
Festo 162061. Twin cylinder DPZ-20-10-P-A-KF
€548.83Excl. 19% VAT , excl. Shipping Cost
Total price
| Distance from centre of gravity of load to yoke plate xs | 50 mm |
| Stroke | 100 mm |
| Piston diameter | 25 mm |
| Operating mode, drive unit | Yoke |
| Cushioning | Elastic cushioning rings/plates at both ends |
| Mounting position | optional |
| Guide | Plain-bearing guide |
| Design | Guidance |
| Position detection | Via proximity switch |
| Symbol | 00991737 |
| Operating pressure | 0.15 MPa ... 1 MPa |
| Operating pressure | 1.5 bar ... 10 bar |
| Max. speed | 0.8 m/s |
| Mode of operation | Double-acting |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Note on operating and pilot medium | Lubricated operation possible (in which case lubricated operation will always be required) |
| Corrosion resistance class CRC | 1 - Low corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Ambient temperature | -20 °C ... 80 °C |
| Impact energy in end positions | 0.3 J |
| Max. force Fy | 810.7 N |
| Max. force Fy static | 810.7 N |
| Max. force Fz | 810.7 N |
| Max. force Fz static | 810.7 N |
| Max. moment Mx | 27.56 Nm |
| Max. torque Mx static | 27.56 Nm |
| Max. moment My | 19.46 Nm |
| Max. torque My static | 19.46 Nm |
| Max. moment Mz | 19.46 Nm |
| Max. torque Mz static | 19.46 Nm |
| Max. permissible torque load Mx as a function of stroke | 3.64 Nm |
| Max. effective load dependent upon stroke at defined distance xs | 86 N |
| Theoretical force at 0.6 MPa (6 bar, 87 psi), return stroke | 247 N |
| Theoretical force at 0.6 MPa (6 bar, 87 psi), advance stroke | 295 N |
| Moving mass | 979 g |
| Product weight | 2225 g |
| alternative connections | See product drawing |
| Pneumatic connection | G1/8 |
| Note on materials | RoHS-compliant |
| Material cover | Wrought aluminium alloy |
| Material seals | NBR |
| Material housing | Wrought aluminium alloy |
| Material piston rod | High-alloy stainless steel |
| Manufacturer Nr. | DFM-25-100-P-A-GF |
|---|---|
| Manufacturer | Festo |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| EAN | 4052568013196 |
| Weight | 2.200000 |
| HS-Code | 84123100 |
| Article authenticity | Original product |
| Condition of article | New |
