Festo 189458. Mini guided drive DFC-6-20-P-A-GF

Name: Festo 189458. Mini guided drive DFC-6-20-P-A-GF
Brand: Festo
SKU: FES-189458
Price: 327.81 EUR
Availability: InStock

€327.81

Excl. 19% VAT , excl. Shipping Cost

Article

FES-189458

Manufacturer Nr.

DFC-6-20-P-A-GF

Mini guided drive

Pictures are for reference and may not be accurate, actual product may differ

Frequently Bought Together

This Item: Festo 189458. Mini guided drive DFC-6-20-P-A-GF
€327.81
Excl. 19% VAT , excl. Shipping Cost
Festo 162065. Twin cylinder DPZ-20-80-P-A-KF
€668.62
Excl. 19% VAT , excl. Shipping Cost
Festo 170907. Guided drive DFM-16-10-P-A-KF
€235.69
Excl. 19% VAT , excl. Shipping Cost

Total price

Distance from centre of gravity of load to yoke plate xs	10 mm
Stroke	20 mm
Piston diameter	6 mm
Operating mode, drive unit	Yoke
Cushioning	Elastic cushioning rings/plates at both ends
Mounting position	optional
Guide	Plain-bearing guide
Design	Guidance
Position detection	Via proximity switch
Symbol	00991737
Operating pressure	0.15 MPa ... 1 MPa
Operating pressure	1.5 bar ... 10 bar
Max. speed	1 m/s
Mode of operation	Double-acting
Operating medium	Compressed air to ISO 8573-1:2010 [7:4:4]
Note on operating and pilot medium	Lubricated operation possible (in which case lubricated operation will always be required)
Corrosion resistance class CRC	2 - Moderate corrosion stress
LABS (PWIS) conformity	VDMA24364-B2-L
Ambient temperature	-5 °C ... 60 °C
Impact energy in end positions	0.008 J
Max. moment Mx	0.1 Nm
Max. effective load dependent upon stroke at defined distance xs	4.8 N
Theoretical force at 0.6 MPa (6 bar, 87 psi), return stroke	12.5 N
Theoretical force at 0.6 MPa (6 bar, 87 psi), advance stroke	17 N
Moving mass	8.8 g
Moving mass for 0 mm stroke	8.8 g
Additional moving mass per 10 mm stroke	2.8 g
Product weight	44 g
Pneumatic connection	M3
Material cover	Wrought aluminium alloy
Material seals	NBR
Material housing	Wrought aluminium alloy
Material piston rod	High-alloy stainless steel

More Information
Manufacturer Nr.	DFC-6-20-P-A-GF
Manufacturer	Festo
GPSR manufacturer information	Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
EAN	4052568150037
Weight	0.065000
HS-Code	84123100
Article authenticity	Original product
Condition of article	New
