Festo 535445. Linear/swivel clamp CLR-25-20-R-P-A

Name: Festo 535445. Linear/swivel clamp CLR-25-20-R-P-A
Brand: Festo
SKU: FES-535445
Price: 326.1 EUR
Availability: InStock

€326.10

Excl. 19% VAT , excl. Shipping Cost

Article

FES-535445

Manufacturer Nr.

CLR-25-20-R-P-A

Linear/swivel clamp

Pictures are for reference and may not be accurate, actual product may differ

Frequently Bought Together

This Item: Festo 535445. Linear/swivel clamp CLR-25-20-R-P-A
€326.10
Excl. 19% VAT , excl. Shipping Cost
Festo 535484. Linear/swivel clamp CLR-25-10-L-P-A-K11-R8
€353.41
Excl. 19% VAT , excl. Shipping Cost
Festo 572359. Hinge cylinder DWC-63-125-Y-G
€139.82
Excl. 19% VAT , excl. Shipping Cost

Total price

Total stroke	33 mm
Piston diameter	25 mm
Piston rod thread	M6
Swivel angle	90 deg +/-3 deg
Clamping stroke	20 mm
Cushioning	Elastic cushioning rings/plates at both ends
Mounting position	optional
Design	Piston Piston rod Cylinder barrel
Position detection	Via proximity switch
Swivel direction	Right
Symbol	00991217
Operating pressure	2 bar ... 10 bar
Mode of operation	Double-acting
Operating medium	Compressed air to ISO 8573-1:2010 [7:4:4]
Note on operating and pilot medium	Lubricated operation possible (in which case lubricated operation will always be required)
Corrosion resistance class CRC	2 - Moderate corrosion stress
LABS (PWIS) conformity	VDMA24364-B2-L
Ambient temperature	-10 °C ... 80 °C
Effective clamping force at 0.2 MPa (2 bar, 29 psi)	63 N
Effective clamping force at 0.4 MPa (4 bar, 58 psi)	127 N
Effective clamping force at 0.6 MPa (6 bar, 87 psi)	188 N
Max. tightening torque Clamping finger screw	12 Nm
Theoretical clamping force at 0.6 MPa (6 bar, 87 psi)	227 N
Product weight	455 g
Type of mounting	Either: With through-hole Via female thread With accessories
Pneumatic connection	M5
Material collar screws	Steel Galvanised
Material cover	Wrought aluminium alloy Coated
Material seals	NBR TPE-U(PU)
Material housing	Wrought aluminium alloy Smooth anodised
Material piston rod	High-alloy stainless steel
Material cylinder barrel	Wrought aluminium alloy Smooth anodised

More Information
Manufacturer Nr.	CLR-25-20-R-P-A
Manufacturer	Festo
GPSR manufacturer information	Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
EAN	4052568168841
Weight	0.470000
HS-Code	84123100
Article authenticity	Original product
Condition of article	New
