Festo 161756. Proximity sensor SME-8-K-24-S6
€44.89
Excl. 19% VAT ,
excl. Shipping Cost
Article
FES-161756
Manufacturer Nr.
SME-8-K-24-S6
Proximity sensor
Frequently Bought Together
-
This Item:
€44.89Excl. 19% VAT , excl. Shipping Cost
-
Festo 551373. Proximity sensor SMT-10M-PS-24V-E-2,5-L-OE
€35.10Excl. 19% VAT , excl. Shipping Cost
-
Festo 171178. Proximity sensor SMTO-8E-PS-S-LED-24
€41.84Excl. 19% VAT , excl. Shipping Cost
Total price
| Design | For T-slot |
| Conforms to standard | EN 60947-5-2 |
| Symbol | 00991624 |
| CE mark (see declaration of conformity) | To EU EMC Directive In accordance with EU RoHS Directive |
| CE marking (see declaration of conformity) | To UK instructions for EMC To UK RoHS instructions |
| Note on materials | RoHS-compliant |
| Instructions on use | Only for fixed cable installation |
| Measured variable | Position |
| Measuring principle | Magnetic reed |
| Ambient temperature | -40 °C ... 120 °C |
| Repetition accuracy | 0.2 mm |
| Switching output | Contacting, bipolar |
| Switching element function | N/O contact |
| Switch-on time | 0.5 ms |
| Switch-off time | 0.03 ms |
| Max. switching frequency | 800 Hz |
| Max. output current | 500 mA |
| Max. switching capacity AC | 10 VA |
| Max. switching capacity DC | 10 W |
| Voltage drop | 0 V |
| Min. load current | 0 mA |
| Short circuit current rating | no |
| Overload protection | Not available |
| Operational voltage range AC | 0 V ... 30 V |
| Operational voltage range DC | 0 V ... 30 V |
| Reverse polarity protection | no |
| Electrical connection 1, connection type | Cable |
| Electrical connection 1, connector system | Open end |
| Electrical connection 1, number of connections/cores | 2 |
| Connection outlet orientation | In-line |
| Cable length | 2.5 m |
| Material cable sheath | TPE-S |
| Type of mounting | Clamped in T-slot Insertable in the slot lengthwise |
| Tightening torque | 0.2 Nm |
| Mounting position | optional |
| Product weight | 50 g |
| Housing colour | Black |
| Material housing | Epoxy resin PET High-alloy stainless steel |
| Ambient temperature with moving cable | -5 °C ... 120 °C |
| Degree of protection | IP67 |
| Insulation voltage | 50 V |
| Immunity to surge | 0.8 kV |
| Vibration resistance to DIN/IEC 68 Part 2-6 | Tested to severity level 2 |
| Continuous shock resistance to DIN/IEC 68 Part 2-82 | Tested to severity level 2 |
| LABS (PWIS) conformity | VDMA24364-B2-L |
| Pollution degree | 3 |
| Manufacturer Nr. | SME-8-K-24-S6 |
|---|---|
| Manufacturer | Festo |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| EAN | 4052568012441 |
| Weight | 0.034000 |
| HS-Code | 85365019 |
| Article authenticity | Original product |
| Condition of article | New |
