Aventics Series MS01 R412011194 MS01-04-5/2XX-SR-G014-GD-AL

Name: Aventics Series MS01 R412011194 MS01-04-5/2XX-SR-G014-GD-AL
Brand: Aventics
SKU: AVE-R412011194
Price: 2356.51 EUR
Availability: InStock

€2,356.51

Excl. 19% VAT , excl. Shipping Cost

Article

AVE-R412011194

Manufacturer Nr.

R412011194

MS01-04-5/2XX-SR-G014-GD-AL

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Pictures are for reference and may not be accurate, actual product may differ

Frequently Bought Together

This Item: Aventics Series MS01 R412011194 MS01-04-5/2XX-SR-G014-GD-AL
€2,356.51
Excl. 19% VAT , excl. Shipping Cost
Aventics Pressure sensor, Series PE5 R412010805 PE5-IO-DA04-000-120-M12
€258.85
Excl. 19% VAT , excl. Shipping Cost
Aventics Valve plug connector, series CON-VP 1834484051 CON-VP-F_BI-2+E-SCREW
€5.25
Excl. 19% VAT , excl. Shipping Cost

Total price

Details

Information

Downloads

Version	4x
Version	MS01-AL test block, variant II, with 5/2-directional valve
Standards	ISO 15407-1
Standards	26 mm
Length	174.5 mm
Grid dimension	27.1 mm
Cleaning pressure option	permanent cleaning pressure
Compressed air connection standard	according to ISO 228-1
Compressed air connection input	G 3/8
Compressed air connection, exhaust	G 1/8
Compressed air connection output	G 1/4
Compressed air connection pilot air exhaust	G 1/8
Working pressure min.	4 bar
Working pressure max	10 bar
Min. ambient temperature	0 °C
Max. ambient temperature	50 °C
Min. medium temperature	0 °C
Max. medium temperature	50 °C
Medium	Compressed air
Max. particle size	5 µm
Oil content of compressed air min.	0 mg/m³
Oil content of compressed air max.	0.1 mg/m³
Protection class	IP65
Duty cycle	100 %
DC operating voltage	24 V

Test block MS01
Operating pressure 4 bar ... 10 bar

More Information
Manufacturer Nr.	R412011194
Manufacturer	Aventics
GPSR manufacturer information	AVENTICS GmbH, Ulmer Straße 4, DE-30880 Laatzen, aventics.com
Weight	3.500000
HS-Code	84123100
Article authenticity	Original product
Condition of article	New
