Multi stage ejectors to 90% vacuum, G 1-1/2", to 1400 l/min

Name: Multi stage ejectors to 90% vacuum, G 1-1/2", to 1400 l/min
Brand: Fluidics equipment
SKU: FL-015976
Price: 1807.07 EUR
Availability: InStock

€1,807.07

Excl. 19% VAT , excl. Shipping Cost

Article

FL-015976

Manufacturer Nr.

VIP 32

Multi stage ejectors to 90% vacuum, G 1-1/2", to 1400 l/min

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Pictures are for reference and may not be accurate, actual product may differ

Frequently Bought Together

This Item: Multi stage ejectors to 90% vacuum, G 1-1/2", to 1400 l/min
€1,807.07
Excl. 19% VAT , excl. Shipping Cost
Spring plunger M 5 (IG)xM 5 (Female thread), stroke 5mm, Standard
€42.13
Excl. 19% VAT , excl. Shipping Cost
Retaining ring (TPU) for suction cup holder, Type C,
€0.53
Excl. 19% VAT , excl. Shipping Cost

Total price

Details

Information

Materials:
Body: anodised aluminium, nozzles: brass, seal: neoprene

Temperature range:
-20 to +100 °C

Operating pressure:
1 to 7 bar (optimum 4 bar)

Pressure gauge connection:
G 1/4"

Advantages:
•high vacuum,
•low cost,
•maintenance free,
•high vacuum, ideal for vacuum packaging or large forces with small suction caps

Suction performance [l/min]	1400
Thread Supply air	G 3/8"
Thread vacuum	G 1-1/2"
Thread exhaust air	G 1-1/2"
Air consumption* [l/min]	500
Silencer**	FFSD 112
Vacuum meter	MW -163
L [mm]	250
B [mm]	97
H [mm]	65,0
Evacuation time (1 ltr. to 10%) [s/l]	0,0040
Evacuation time (1 ltr. to 20%) [s/l]	0,0200
Evacuation time (1 ltr. to 30%) [s/l]	0,040
Evacuation time (1 ltr. to 40%) [s/l]	0,080
Evacuation time (1 ltr. to 50%) [s/l]	0,130
Evacuation time (1 ltr. to 60%) [s/l]	0,250
Evacuation time (1 ltr. to 70%) [s/l]	0,35
Evacuation time (1 ltr. to 90%) [s/l]	2,0
Flow at 0% vacuum [l/min]	1.400
Flow at 10% vacuum [l/min]	980
Flow at 20% vacuum [l/min]	480
Flow at 30% vacuum [l/min]	220
Flow at 40% vacuum [l/min]	120
Flow at 60% vacuum [l/min]	80
Flow at 80% vacuum [l/min]	27,0

More Information
Manufacturer Nr.	VIP 32
Manufacturer	Fluidics equipment
EAN	4050571720308
Weight	28.000000
HS-Code	84141089
Article authenticity	Original product
Condition of article	New
