M-2112-ES-24V. 2/2-way ES solenoid valve G 1-1/2", 0,5 to 16 bar, closed (NC) without power

Materials:
Body G 1/8" and G 1/4": 1.4104, G 1/2" to G 2": 1.4581 (internal parts 1.4104), seal: FKM

Temperature range:
-20°C to +130°C, ambience: -10°C to +50°C

Media:
Compressed air, neutral gases, water, neutral low-viscosity media, other media on request

Installation position:
With upright magnets, (G 3/8" - G 2" also with horizontal magnets)

Control voltages:
Standard: 24 V DC, 230 V AC, upon request other voltages

Voltage tolerance:
± 10 %

Protection class:
IP 65 (plug size 3)

Information:
These valves are always supplied with a solenoid coil and a connector plug.

Warning:
For opening or closing, servo-controlled valves require a pressure difference between the valve inlet and valve outlet. The pressure difference is given as minimum pressure. There is a pressure compensation in the valve, resulting that no or little medium is used at the valve outlet, the valve will no longer function (it opens or closes unreliably).
