Cable with M12 coupling, 4-wire, 10 m, angled

Description:
Pre-assembled connecting cables with M 12 female connector (M 12x1 female thread to DIN EN 61076-2-101, A-coded, 5-pin) on one end and loose cable ends or M 12 male connector (M 12x1 male thread to DIN EN 61076-2-101, A-coded, 5-pin) on the other

Temperature range:
-25 to +90 °C

Voltage:
max. 60 V AC/DC, max. 4 A

Protection class:
IP 67

Cable:
PUR cable, 4 or 5x 0.34 mm² (only for static applications)

Cable layout:
Pin 1 - brown, Pin 2 - white, Pin 3 - blue, Pin 4 - black, Pin 5 - grey (only present if 5-core)

Suitable:
These cables are preferred for use for connecting electronic pressure switches, inductive proximity switches, photo switches or as power supplies for valve clusters / valve terminals. The 5-pole socket fits M 12 plugs with 5 and 4 pins.

Design	angled
Cable end 1	M 12 socket (A-coded)
Cable end 2	5 loose cable ends (Pin 1 to 5)
Cable length [MTR]	10
Number of cores	5
