K-41406. 4/2-way toggle valve G 1/4"-6 mm

Materials:
Body: Nickel-plated brass, internal parts: brass / stainless steel, seal: NBR

Temperature range:
-5°C to +70°C

Operating pressure:
0 - 8 bar (banjo valve 2/2-way and 3/2-way with pressure inlet ring piece: 0 - 10 bar)

Media:
lubricated and unlubricated, filtered compressed air, neutral gases

Advantages:
•low price,
•extensive application options,
•simple and fast setting up of a circuit,
•rocker lever can be positioned

Application:
For the actuation of double-acting cylinders, use the valve directly in a connection of the cylinder. Using the hose, connect the upper banjo with the other connection of the cylinder. The valve is supplied with compressed air by means of the lower banjo.

Flow:
350 l/min

Nominal width:
3,5 mm

Required mounting hole for panel mounting:
Ø 12.5 mm, maximum sheet thickness: 4 mm (bulkhead thread: M 12x1)
