851,88 €
Excl. 19% VAT ,
excl. Shipping Cost
Artículo
FL-XLK-125/320
Número del fabricante
XLK 125/320
ISO 15552 cylinders, piston 125 mm, stroke 320 mm
Comprados con frecuencia juntos
-
Este artículo:
851,88 €Excl. 19% VAT , excl. Shipping Cost
-
Airtec XL 32/600-EK. ISO 15552 cylinders, piston 32 mm, stroke 600 mm
180,22 €Excl. 19% VAT , excl. Shipping Cost
-
Airtec XLK 40/25. ISO 15552 cylinders, piston 40 mm, stroke 25 mm
197,28 €Excl. 19% VAT , excl. Shipping Cost
Total price
Materials:
Head and foot: stove-enamelled die-cast aluminium, cylinder tube: anodized aluminium profile tube, piston rod: hard chromium plated steel, piston: complete piston (ST / NBR), seal: NBR / PUR
Temperature range:
-20°C to +80°C
Operating pressure:
max. 10 bar
Optional:
FKM seals (temperature range: -10°C to max. +150°C, without magnetic piston) -V, stainless steel piston rod -EK, ATEX approval Ex II 2GD c T5 T100° -20°C <=Ta<= 80°C -X
Version:
with magnetic pistons and adjustable end position damping
Cylinder switch type:
D, A
Head and foot: stove-enamelled die-cast aluminium, cylinder tube: anodized aluminium profile tube, piston rod: hard chromium plated steel, piston: complete piston (ST / NBR), seal: NBR / PUR
Temperature range:
-20°C to +80°C
Operating pressure:
max. 10 bar
Optional:
FKM seals (temperature range: -10°C to max. +150°C, without magnetic piston) -V, stainless steel piston rod -EK, ATEX approval Ex II 2GD c T5 T100° -20°C <=Ta<= 80°C -X
Version:
with magnetic pistons and adjustable end position damping
Cylinder switch type:
D, A
| Número del fabricante | XLK 125/320 |
|---|---|
| Fabricante | Airtec |
| EAN | 4050571801762 |
| Peso | 1.000000 |
| Número de arancel | 84123100 |
| Autenticidad del artículo | Producto original |
| Estado del artículo | Nuevo |
